| Series | Length | Bit Diameter (D) | Weight [Appx.] | Part# | Ref. Part# | |||
|---|---|---|---|---|---|---|---|---|
| 11 | 400 mm 800 mm 1600 mm 2400 mm 3200 mm 4000 mm 4800 mm 5600 mm 6400 mm 7200 mm 8000 mm |
1'3" ft 2'7" ft 5'3" ft 7'10" ft 10'6" ft 13'1" ft 15'9" ft 18'4" ft 21' ft 23'7.5" ft 26'3" ft |
35 mm 34 mm 33 mm 32 mm 31 mm 30 mm 29 mm 28 mm 27 mm 26 mm 25 mm |
1.35 inch 1.30 inch 1.25 inch 1.20 inch 1.18 inch 1.14 inch 1.10 inch 1.06 inch 1.02 inch 0.98 inch 0.94 inch |
1.50 kg 3.00 kg 5.40 kg 7.90 kg 10.30 kg 12.60 kg 15.10 kg 17.60 kg 19.90 kg 22.30 kg 25.00 kg |
3.00 lb 6.50 lb 12.00 lb 17.50 lb 22.50 lb 27.70 lb 33.20 lb 38.70 lb 43.80 lb 49.00 lb 55.00 |
11-400-35 11-800-34 11-1600-33 11-2400-32 11-3200-31 11-4000-30 11-4800-29 11-5600-28 11-6400-28 11-7200-26 11-8000-25 |
- 714-0834,05-02 714-1633,05-02 714-2432,05-02 714-3231,05-02 714-4030,05-02 714-4829,05-02 714-5628,05-02 714-6427,05-02 714-7226,05-02 - |
| 12 | 400 mm 800 mm 1600 mm 2400 mm 3200 mm 4000 mm 4800 mm 5600 mm 6400 mm 7200 mm 8000 mm |
1'3" ft 2'7" ft 5'3" ft 7'10" ft 10'6" ft 13'1" ft 15'9" ft 18'4" ft 21' ft 23'7" ft 26'3" ft |
41 mm 40 mm 39 mm 38 mm 37 mm 36 mm 35 mm 34 mm 33 mm 32 mm 31 mm |
1.61 inch 1.56 inch 1.53 inch 1.50 inch 1.46 inch 1.40 inch 1.38 inch 1.35 inch 1.30 inch 1.26 inch 1.22 inch |
1.50 kg 3.00 kg 5.40 kg 7.90 kg 10.30 kg 12.60 kg 15.10 kg 17.60 kg 19.90 kg 22.30 kg 25.00 kg |
3.00 lb 6.50 lb 12.00 lb 17.50 lb 22.50 lb 27.70 lb 33.20 lb 38.70 lb 43.80 lb 49.00 lb 55.00 lb |
12-400-41 12-800-40 12-1600-39 12-2400-38 12-3200-37 12-4000-36 12-4800-35 12-5600-34 12-7200-32 12-8000-31 |
- 714-0840,05-02 714-1639,05-02 714-2438.05-02 714-3237,05-02 714-4036,05-02 714-4835,05-02 714-5634,05-02 714-6433,05-02 714-7232,05-02 714-8031,05-02 |
| 13 | 400 mm 800 mm 1200 mm 1600 mm 2000 mm |
1'3" ft 2'7" ft 3'11" ft 5'3" ft 6'6" ft |
34 mm 33 mm 32 mm 31 mm 30 mm |
1.35 inch 1.30 inch 1.25 inch 1.22 inch 1.19 inch |
1.70 kg 3.00 kg 4.20 kg 5.30 kg 6.50 kg |
3.75 lb 6.60 lb 9.25 lb 11.70 lb 14.30 lb |
13-400-34 13-800-33 13-1200-32 13-1600-31 13-2000-30 |
714-0434,05-02 714-0833,05-02 714-1232,05-02 714-1631,05-02 714-2030,05-02 |
| 16 | 600 mm 1200 mm 1800 mm 2400 mm |
1'11" ft 3'11" ft 5'10" ft 7'10" ft |
35 mm 34 mm 33 mm 32 mm |
1.37 inch 1.34 inch 1.31 inch 1.25 inch |
2.40 kg 4.20 kg 6.10 kg 7.90 kg |
5.30 lb 9.25 lb 13.50 lb 17.40 lb |
16-600-35 16-1200-34 16-1800-33 16-2400-32 |
714-0635,05-02 714-1234,05-02 714-1833,05-02 714-2432,05-02 |
| 17 | 600 mm 1200 mm 1800 mm 2400 mm |
1'11" ft 3'11" ft 5'10" ft 7'10" ft |
41 mm 40 mm 39 mm 38 mm |
1.62 inch 1.56 inch 1.53 inch 1.50 inch |
2.40 kg 4.30 kg 6.10 kg 7.80 kg |
5.30 lb 9.25 lb 13.50 lb 17.40 lb |
17-600-41 17-1200-40 17-1800-39 17-2400-38 |
714-0641,05-02 714-1240,05-02 714-1839,05-02 714-2438,05-02 |
