Thread | Dia | Length | MTS Part # | Reference Part # | ||
---|---|---|---|---|---|---|
R22 R25 R28 R32 R38 T38 T45 T51 |
31 mm 36 mm 44 mm 44 mm 55 mm 55 mm 63 mm 71 mm |
1.22" 1.38" 1.75" 1.75" 2.16" 2.16" 2.50" 2.80" |
140 mm 150 mm 150 mm 150 mm 170 mm 191 mm 210 mm 225 mm |
5.50" 6" 6" 6" 6.75" 7.50" 8.25" 8.86" |
CSR2222-140-31 CSR2525-150-36 CSR2828-150-44 CSR3232-150-44 CSR3838-170-55 CSR3838-191-55 CSR4545-210-63 CSR5151-225-71 |
7991-2031 7992-2035 - 7993-3644 7994-3655 7314-3652 7315-3663 7316-3671 |
