| MTS Part # | Reference Part # | Thread | Lenght | Dia | Body | ||
|---|---|---|---|---|---|---|---|
| ER800 - R22R22 ER1200 - R22R22 ER1600 - R22R22 ER2400 - R22R22 ER3200 - R22R22 |
7851 - 1308 - 20 7851 - 1312 - 20 7851 - 1316 - 20 - - |
R22 - R22 | 800 mm 1200 mm 1600 mm 2400 mm 3200 mm |
2’7” 3’11” 5’3” 7’10” 10’6” |
22 mm | 7⁄8" | Hex |
| ER610 - R32R32 ER915 - R32R32 ER1220 - R32R32 ER1830 - R32R32 ER2440 - R32R32 ER3050 - R32R32 ER3660 - R32R32 |
- - - - 7853 - 3324 - 30 7853 - 3331 - 30 7853 - 3337 - 30 |
R32 - R32 | 610 mm 915 mm 1220 mm 1830 mm 2440 mm 3050 mm 3660 mm |
2 " 3 " 4 " 6 " 8 " 10 " 12 " |
32 mm | 1¼” | Round |
| ER1220 - R38R38 ER1830 - R38R38 ER2345 - R38R38 ER3050 - R38R38 |
- - - - |
R38 - R38 | 1220 mm 1830 mm 2435 mm 3050 mm |
4 " 6 " 8 " 10 " |
39 mm | 1½" | Round |
| ER4305 - T38R32 ER4915 - T38R32 ER5525 - T38R32 ER6135 - T38R32 |
- - - - |
R38 - R32 | 4305 mm 4915 mm 5525 mm 6135 mm |
14 " 16 " 18 " 20 " |
39 mm | 1½" | Round |
| ER3050 - T45T45 ER3660 - T45T45 ER4265 - T45T45 ER6095 - T45T45 |
7325 - 7331C - 30 7325 - 7337C - 30 7325 - 7343C - 30 - |
T45 - T45 | 3050 mm 3660 mm 4265 mm 6095 mm |
10 " 12 " 13 " 20 " |
45 mm | 1 x 4/5" | Round |
| ER3660 - T51T51 ER4265 - T51T51 ER6095 - T51T51 |
7326 - 7337C - 30 7326 - 7343C - 30 - |
T51 - T51 | 3660 mm 4265 mm 6095 mm |
12 " 13 " 20 " |
52 mm | 2" | Round |
