MTS 658-Pneumatic Rock Drill

MTS 658 is the most popular handheld rock drill (Jack Hammer), globally. In relation to weight, it delivers a very high penetration rate at very low air consumption. Mostly used in Quarry work, Blast hole drilling, Tunneling, construction sites, etc. With H22 integral / extension steels, it can drill up to 6 meters with 27-40 mm dia holes. If you prefer a lighter version in Rock Drills, then you can look for MTS 571



Where it is used?

  • Quarry work
  • Blast hole drilling
  • Tunnelling
  • Construction sites
    • Sinker Drill Model # MTS 658 Pneumatic Rock Drill
    Weight 24 kg 53 lb
    Length 565 mm 22.2"
    Hole Range 27mm -40mm 1.06"-1.57"
    Hole Depth 6 meters 19.6ft
    Air Pressure 6 bar 87 psi
    Air Consumption 58l/s 123 cfm
    Blow per minute 2040
    Revolution 215rpm
    Piston dia 65 mm 2.56"
    Piston stroke 59 mm 2.32"
    Air inlet(BSP) 19mm 3/4"
    Shank size-8311030186 22x108 mm 7/8" x 4ΒΌ"
